Engineered for Heavy-Duty Truck Parking/Starting Power/Outdoor Energy Storage
| Product Model | Nominal Capacity (Ah) | Nominal Voltage (V) | Standard Cycles (times/25℃) | Internal Resistance (mΩ) | Weight (g) | Width×Thickness×Height (mm) | Energy Density (Wh/kg) | Recommended Application |
| LF22K | 22 | 3.22 | 4500 | 0.43±0.1 | 628±10 | 148.7×17×131.8 | 112 | EV |
| LF100LA | 102 | 3.20 | 5000 | ≤0.5 | 1985±100 | 160.0×50.1×118.5 | 164 | ESS |
| LF105 | 105 | 3.20 | 4000 | 0.32±0.05 | 1980±60 | 130.3×56.3×200.5 | 169 | ESS/EV |
| LF125H | 125 | 3.22 | 4000 | 0.29±0.05 | 2310±69 | 200.4×77.7×115.0 | 174 | EV |
| LF150 | 150 | 3.22 | 4000 | 0.40±0.05 | 2850±84 | 200.7×53.2×207.0 | 170 | EV |
| LF168 | 168 | 3.22 | 4000 | 0.37±0.03 | 3020±90 | 200.7×53.2×207.0 | 179 | EV |
| LF173 | 173 | 3.22 | 4000 | 0.25±0.05 | 3190±96 | 173.9×41.0×207.5 | 174 | EV |
| LF202 | 202 | 3.22 | 4000 | TBD | 3469±30 | 200.7×64.5×125.0 | 187 | ESS/EV |
| LF206 | 206 | 3.22 | 4000 | 0.31±0.05 | 3500±105 | 200.7×55.9×218.2 | 189 | EV |
| LF230 | 230 | 3.20 | 4000 | 0.24±0.05 | 4140±124 | 173.9×53.8×207.2 | 177 | EV |
| LF280K-V1 | 280 | 3.20 | 6000 | ≤0.25 | 5420±300 | 173.7×72.0×207.2 | 165 | ESS |
| LF280K-V3 | 280 | 3.20 | 8000 | ≤0.25 | 5490±300 | 173.7×71.7×206.8 | 163 | ESS |
| LF304 | 304 | 3.20 | 4000 | 0.16±0.05 | 5450±164 | 173.7×71.7×207.2 | 178 | EV |
| MB31 | 314 | 3.20 | 8000 | 0.18±0.05 | 5600±300 | 173.7×71.7×207.2 | 179 | ESS |
| MB56 | 628 | 3.20 | 8000 | 0.11±0.05 | 11300±300 | 352.3×71.7×207.2 | 177 | ESS |
| A24 | 1721 | 3.20 | 2000 | ≤0.5 | 3160±40 | 301.0×36.7×132.5 | 174 | EV |
| A25 | 132.2 | 3.20 | 1500 | ≤0.6 | 2281±35 | 314.0×30.5×107.0 | 185 | EV |
| A27-V1 | 127.2 | 3.21 | 3000 | ≤0.45 | 2220±30 | 309.5×37.2×88.0 | 183 | EV |
| A27-V21 | 124.9 | 3.22 | 1500 | ≤0.33 | 2239±30 | 309.5×37.2×88.0 | 179 | EV |
| A41-V1 | 106 | 3.22 | 2000 | ≤0.40 | 1880±30 | 148.6×52.2×118.5 | 181 | EV |
| A41-V21 | 116 | 3.22 | 2500 | ≤0.35 | 1985±30 | 148.6×52.3×119.0 | 188 | EV |
| A41-V31 | 122 | 3.22 | 2500 | ≤0.33 | 2035±30 | 148.6×52.3×119.0 | 193 | EV |
?Key Benefits
-
?Guaranteed by 400GWh Cell Supply Chain?
- High-consistency LiFePO4 cells sourced directly from Tier-1 manufacturers in Hubei, ensuring stable supply and rigorous quality control.
-
?Military-Grade Safety Standards?
- Passed nail penetration, overcharge, and extreme heat tests (thermal runaway >800°C), ideal for heavy-duty applications.
-
?5,000+ Cycle Lifespan?
- Advanced cell technology delivers 80%+ capacity retention after 3,000 cycles, perfect for long-term energy storage.
-
?-30°C Low-Temperature Operation?
- Proprietary electrolyte enables reliable cold-start performance and fast charging in extreme climates.
Applications
- Truck Parking Systems?: 50% lighter than lead-acid, supporting 24/7 HVAC and onboard electronics.
- ?Commercial Vehicle Starters?: Instant high-power discharge to prevent diesel battery failure.
- ?Off-Grid Energy Storage?: Scalable 5kWh–1MWh modular designs with solar compatibility.
Why Choose WES Battery?
- Strategic Manufacturer Partnerships?: Cost-optimized cells + joint R&D for customized solutions.
- ?End-to-End Support?: Free BMS integration, structural design, and global certification (UN38.3/CE/UL).
?Call to Action?: Contact WES Battery today for your OEM/ODM solution!
]]>Short Description
The WES 1047140 is a 7500mAh 3.85V lithium-ion battery with 30C high discharge rate, designed for power-hungry applications like drones, RC vehicles, and industrial devices. Supports full customization.
Technical Specifications
Model? |
1047140 |
?Nominal Voltage? |
3.85V |
?Capacity? |
7500mAh |
?Discharge Rate? |
30C Continuous |
?
Dimensions? |
10.3*47*142mm |
?Weight? |
130g |
?
Customization? |
Voltage/Capacity/Discharge Rate |
Applications
-
?Drones & UAVs?
-
?RC Models?
-
?Power Tools?
-
?Industrial Equipment
Customization
WES offers full customization for lithium polymer batteries, including voltage adjustment (3.2V-4.35V), capacity scaling (5000mAh-50Ah), and discharge rate optimization (10C-50C). Contact us for OEM/ODM solutions.
Support & Warranty
- Quality Assurance?：ISO 9001 Certified
- ?Warranty?：12-Month Limited Warranty
- ?Shipping?：Global Delivery (DHL/FedEx)
WES Lithium Battery Manufacturer
High Rate Lithium Polymer Batteries
]]>The WES 24V 350Ah LiFePO4 rechargeable lithium?ion truck battery is an OEM?grade power solution engineered for heavy?duty vehicles and fleet integration.
Using custom Class A LiFePO4 cells and an integrated battery management system (BMS), the 24V 350Ah pack delivers long life, superior safety, and smart remote monitoring—reducing maintenance and total cost of ownership for OEMs.
Key Features
- Voltage & Capacity:?24V,?350Ah?(nominal)
- Chemistry:?LiFePO4 battery?(rechargeable lithium?ion battery) with Class A cell quality
- Cycle Life & Durability:?30,000+ cycles; estimated service life?~10 years?under typical duty profiles
- Energy Example: scalable pack configurations support multi?kWh systems for auxiliary loads (e.g., parking A/C)
- Safety: anti?puncture, anti?collision, anti?extrusion design; enhanced thermal stability and passive safety of LiFePO4 chemistry
- Temperature Range: operational?-40℃ to 60℃?for extreme climates
- Smart BMS: one?click alarm, remote control, real?time monitoring, intelligent positioning, cell balancing, and protective cutoffs
- Installation: ruggedised enclosure, vibration?resistant mounting; designed to meet international OEM sizing norms
- Warranty & Supply:?2?year?warranty with UK stock available for rapid fulfilment
Performance & Benefits for OEMs
- Long duration and high power density reduce battery swaps and service interventions. Example: a well?sized 24V LiFePO4 pack can sustain auxiliary loads for extended parking periods, lowering engine idling and fuel consumption.
- High cycle life and maintenance?free operation drive significant TCO savings versus lead?acid alternatives—one WES pack can replace multiple lead?acid sets and auxiliary generators over its lifecycle.
- Enhanced safety and wide temperature tolerance simplify integration into global vehicle platforms.
Business and support
Supplied in Chinese brand factories; sample programs and engineering specification packages are available.
Please contact WES Sales for data sheets, pricing and delivery times.
CTA
Request datasheet & sample — contact WES OEM Sales E-mail：sales001@m.nczcnj.com
]]>Short Description
The WES 9090190 is a 20000mAh 3.85V lithium polymer battery with 20C high discharge rate, designed for power-hungry applications like drones, RC vehicles, and industrial devices. Supports full customization.
Technical Specifications
Model? |
9090190 |
?Nominal Voltage? |
3.85V |
?Capacity? |
20000mAh |
?Discharge Rate? |
20C Continuous |
?
Dimensions? |
9.2*91*192mm |
?Weight? |
327g |
?
Customization? |
Voltage/Capacity/Discharge Rate |
Applications
-
?Drones & UAVs?
-
?RC Models?
-
?Power Tools?
-
?Industrial Equipment
Customization
WES offers full customization for lithium polymer batteries, including voltage adjustment (3.2V-4.35V), capacity scaling (5000mAh-50Ah), and discharge rate optimization (10C-50C). Contact us for OEM/ODM solutions.
Support & Warranty
- Quality Assurance?：ISO 9001 Certified
- ?Warranty?：12-Month Limited Warranty
- ?Shipping?：Global Delivery (DHL/FedEx)
WES Lithium Battery Manufacturer
High Rate Lithium Polymer Batteries
]]>The WES 12.8V 150Ah LiFePO4 battery (12.8V / 1920Wh) is a direct drop?in replacement for 12.8V lead?acid packs, engineered for long life, high discharge performance and safe, low?maintenance operation. With A?grade LiFePO4 cells, advanced BMS protections and Bluetooth/4G monitoring options, WES 12.8V100Ah is ideal for RVs, boats, solar storage, forklifts and vehicle start/aux systems.
Why choose WES 12V100Ah
- Long lifecycle and lower TCO —?~2500 cycles, far exceeding typical lead?acid life.
- Reliable power for starts and peaks — continuous?1C?discharge and?300A peak (3s)?for engine start and heavy loads.
- True usable capacity —?150Ah / 1920Wh?with flat voltage profile for consistent device performance.
- Drop?in flexibility — supports series/parallel wiring for larger systems and customizable housing to match Group sizes or OEM mounts.
- Integrated safety & monitoring — BMS protects against short?circuit, over?charge, over?discharge, over?current and temperature; LGD display plus Bluetooth/4G (optional) for remote diagnostics.
- Wide operating range — charge 0–55°C, discharge -20–65°C, storage -20–45°C.
Technical highlights
-
Model: WES 12.8V150Ah
- Chemistry: A?grade LiFePO4 cells
- Nominal voltage / energy:?12.8V / 1920Wh
- Capacity:?150Ah
- Charge cutoff: 14.6V; Discharge cutoff: 10V
- Standard charge: 0.5C; Continuous discharge: 1C; Peak: 300A/3s
- Cycle life: ~2500 cycles
- Display & comms: LGD; Bluetooth & optional 4G
- Housing: plastic (dimensions customizable)
- Expandability: series & parallel supported
- BMS features: short?circuit, over?charge, over?discharge, over?current, temperature protections, cell balancing
Applications
- RV & motorhome house battery — long run time for appliances, air conditioners and lighting.
- Marine & boating battery — lighter weight and safer chemistry for onboard systems.
- Off?grid & solar storage — reliable 12V battery bank for home or cabin energy.
- Automotive start/aux — EV 12V replacement, trucks, forklifts, scooters and motorcycles.
- Industrial & AGV equipment — durable power for continuous operation and high?current demands.
The WES 12V 100Ah LiFePO4 battery (12.8V / 1280Wh) is a direct drop?in replacement for 12V lead?acid packs, engineered for long life, high discharge performance and safe, low?maintenance operation. With A?grade LiFePO4 cells, advanced BMS protections and Bluetooth/4G monitoring options, WES 12V100Ah is ideal for RVs, boats, solar storage, forklifts and vehicle start/aux systems.
Why choose WES 12V100Ah
- Long lifecycle and lower TCO —?~2500 cycles, far exceeding typical lead?acid life.
- Reliable power for starts and peaks — continuous?1C?discharge and?300A peak (3s)?for engine start and heavy loads.
- True usable capacity —?100Ah / 1280Wh?with flat voltage profile for consistent device performance.
- Drop?in flexibility — supports series/parallel wiring for larger systems and customizable housing to match Group sizes or OEM mounts.
- Integrated safety & monitoring — BMS protects against short?circuit, over?charge, over?discharge, over?current and temperature; LGD display plus Bluetooth/4G (optional) for remote diagnostics.
- Wide operating range — charge 0–55°C, discharge -20–65°C, storage -20–45°C.
Technical highlights
-
Model: WES 12V100Ah
- Chemistry: A?grade LiFePO4 cells
- Nominal voltage / energy:?12.8V / 1280Wh
- Capacity:?100Ah
- Charge cutoff: 14.6V; Discharge cutoff: 10V
- Standard charge: 0.5C; Continuous discharge: 1C; Peak: 300A/3s
- Cycle life: ~2500 cycles
- Display & comms: LGD; Bluetooth & optional 4G
- Housing: plastic (dimensions customizable)
- Expandability: series & parallel supported
- BMS features: short?circuit, over?charge, over?discharge, over?current, temperature protections, cell balancing
Applications
- RV & motorhome house battery — long run time for appliances, air conditioners and lighting.
- Marine & boating battery — lighter weight and safer chemistry for onboard systems.
- Off?grid & solar storage — reliable 12V battery bank for home or cabin energy.
- Automotive start/aux — EV 12V replacement, trucks, forklifts, scooters and motorcycles.
- Industrial & AGV equipment — durable power for continuous operation and high?current demands.
?Safest LFP Technology:?Cobalt-free, ensuring eco-friendly and reliable energy storage.
Long Lifespan:?Over 4,500 cycles at 85% DOD, providing exceptional longevity.
Customizable Capacity:?Standard module capacity can be tailored to your needs.
Self-Engineered BMS:?Features cell-level monitoring and comprehensive protection against short circuits, overcurrent,
overvoltage, and overtemperature.
Bluetooth APP:?Available on request for real-time battery status monitoring.
Robust Design:?Strong metal casing in black, IP67 waterproof rating for durability in harsh conditions.
OEM Services:?Custom branding options available.
品詳情頁B3_09-1.jpg)
品詳情頁B3_10-1.jpg)
品詳情頁B3_11-1.jpg)
?WES High-Performance AGV Battery Solutions?
Engineered for industrial automation, WES AGV batteries with ?LiFePO4 cell technology? deliver ?10,000+ cycles? at 80% capacity retention, powering Autonomous Guided Vehicles in harsh environments (-30℃~60℃).
?Key Features?
?Ultra-Long Cycle Life?
LiFePO4 chemistry ensures 3x longer service life than standard lithium-ion
?Smart Energy Management?
WES proprietary BMS with:
?Real-time SOC monitoring
?Overcharge/over-discharge protection
?CAN bus communication
?Ruggedized Design?
IP67 enclosure withstands vibration (up to 5G) and humidity (95% non-condensing)
?Technical Specifications?
?Voltage options: 24V/48V/72V DC
?Continuous discharge: 2C (Custom 5C available)
?Charge time: 1.5h (0%~100% @25℃)
?Certifications: UN38.3, CE, UL1973
?Why WES AGV Batteries??
As the preferred power source for Fortune 500 logistics centers, WES provides:
?Modular battery swapping systems
?5-year performance warranty
?24/7 remote diagnostics
Download spec sheet:?[WES-AGV-Series_2025]
![[WES-AGV-Series_2025]](http://m.nczcnj.com/wp-content/uploads/2025/07/006-scaled.jpg){kind=link}
?? ?2500A High Cranking Current? – Delivers instant engine starting, even in extreme weather conditions ranging from -40°C to 60°C. ?? ?3.84kWh Large Capacity? – Supplies continuous power for air conditioning and electronics during vehicle downtime, reducing engine idling and saving fuel. ??? ?Advanced Battery Management System (BMS)? – Features overcharge protection, temperature monitoring, and cell balancing to extend battery lifespan. ?? ?Durable Lithium Iron Phosphate (LiFePO4) Technology? – Offers over 3000 charge cycles, three times longer than traditional lead-acid batteries. ?? ?IP65 Rated & Robust Construction? – Specifically designed for heavy-duty truck starting battery applications, ensuring durability and reliability.
?Perfect For?: ?? ?24V Heavy-Duty Vehicles? (Trucks, Buses, Construction Equipment) ??? ?OEMs & Fleet Operators? Seeking Reliable Engine Starting Solutions ?? ?Cold-Weather Regions? Where Traditional Batteries Often Fail
?Why Choose WES?? ? ?Global OEM Support? for Custom Heavy-Duty Truck Starting Battery Solutions ? ?Rapid Charging? (0.5C/1C) & Extended Battery Lifespan ? ?Bluetooth & 4G Monitoring? for Real-Time Battery Health Tracking
]]>
]]>
